MINI CORNICHE Ceiling recessed

Photometry Filter

Lumen (lm)Colour Temperature (K)DistributionIESBIM
2503,000121°
2604,00013°
7503,00013°
7804,00013°
1,5003,00013°
1,5604,00013°
3,0003,00013°
3,1204,00013°
2,2603,00013°
2,3504,00013°
2603,00026°
2704,00026°
7703,00026°
8004,00026°
1,5403,00026°
1,6104,00026°
3,0903,00026°
3,2204,00026°
2,3203,00026°
2,4204,00026°
123
Download all Photometry and BIM Data

Key Features

The applications are almost limitless: from the lighting of facades and big walls to the enhancement of monuments or architectures. A lighting system that is flexible and customizable, available in various sizes and powers. The stainless steel product can operate in immersion and out of water. MINI CORNICHE is developed as recessed walk over fitting or to light the surfaces from below and as a wall light.

Applications

Distribution

121°
13°
26°
40°
Diffuse
Elliptical

Specification

Extruded aluminium alloy body. A4 Stainless steel screws. External power supply with 12/24V DC constant-current transformer, to be wired in parallel. Gore valve to prevent condensing. The product is subjected to galvanic anodizing treatment divided into distinct phases: mechanical satin finishing, surface degreasing, anodic oxidation and finally fixing. Subsequently the product is painted by performing a double pass in-line process, which allows you to generate a single thick protective layer which then generates barrier against atmospheric agents and UV rays. This allows to achieve corrosion resistance performance in salt spray. Pre-treatment with atmospheric pressure plasma is carried out on the surface before gluing of the diffuser on Platek products. Built-in version installation cast in concrete with a 20-30 cm gravel drainage bed. Only an IP68 connection to the power supply can guarantee the same protection to the appliance.

 Copy specification to clipboard

Dimensions
